Description
Specifications
- 2 Channels for Stereo DJ Programmes.
- High fidelity sound output at low distortion.
- Dual channel dierct coupled amplifier.
- Individual bar-graph for each channel with clip indication.
- Stereo/Mono Selector switch.
- Short circuit, Overload & Overtemp. protection.
- Force cooling for both channels
| SPECIFICATIONS | AB-5000V2 |
| CONTINUOUS RATED
POWER |
2650+2650W RMS Max. For each Zone |
|
STEREO/MONO
BRIDGED OUTPUT |
8Ω :1525+1525W RMS,
4Ω :1950+1950W RMS 2Ω : 2500+2500W RMS @ 10% THD
8Ω :3800W RMS, 4Ω :4700W RMS |
|
TONE CONTROLS
|
BASS : (100Hz) ± 10dB for each Zone
MID : (1KHz) ± 10dB for each Zone TREBLE : (10KHz) ± 10dB for each Zone |
| INPUT SENSITIVITY | Eq. In : 200mV
0dBm (775mV) |
| INPUT IMPEDANCE | 10K Unbalanced |
| CHANNEL
SEPARATION |
70dB @ 1KHz |
| DAMPING FACTOR | 500:1 @ 8Ω Load |
| PROTECTIONS | Temp. DC Short Circuit Overload |
| COOLING | 4 AC Fan (120mm x 120mm) |
| FREQUENCY
RESPONSE(-2db) |
30-20000Hz |
| POWER SUPPLY | 220~240V, 50/60Hz |
| DIMENSIONS
/WEIGHT |
W 490 x H 140 x D x530mm/33.10 Kg |
